| Part Number |
L (uH) |
Tolerance |
Rdc（mΩ） Max.[Typ.] |
Isat（A） Max.[Typ.] |
Itemp（A） Max.[Typ.] |
|||||||||||||||||||||
| BPS252008S-R47M-TB6 | 0.47 | ±20％ | 29 [25] | 4.5 [5.0] | 3.7 [4.0] | |||||||||||||||||||||
| BPS252008S-R47M-TB8 | 0.47 | ±20％ | 24 [20] | 6.0 [6.7] | 4.2 [4.7] | |||||||||||||||||||||
| BPS252008S-1R0M-TB6 | 1.0 | ±20％ | 48 [40] | 4.0 [4.5] | 3.4 [3.7] | |||||||||||||||||||||
| BPS252008S-1R0M-TB8 | 1.0 | ±20％ | 40 [34] | 3.6 [4.0] | 3.6 [4.0] | |||||||||||||||||||||
| BPS252008S-1R5M-TB6 | 1.5 | ±20％ | 69 [60] | 3.5 [4.0] | 3.0 [3.3] | |||||||||||||||||||||
| BPS252008S-2R2M-TB6 | 2.2 | ±20％ | 109 [95] | 2.6 [3.1] | 2.5 [2.8] | |||||||||||||||||||||
| BPS252008S-2R2M-TB8 | 2.2 | ±20％ | 74 [62] | 2.7 [3.0] | 2.4 [2.7] | |||||||||||||||||||||
| BPS252008S-3R3M-TB6 | 3.3 | ±20％ | 150 [132] | 2.0 [2.5] | 2.1 [2.4] | |||||||||||||||||||||
| BPS252008S-4R7M-TB6 | 4.7 | ±20％ | 207 [180] | 1.7 [2.2] | 1.7 [1.9] | |||||||||||||||||||||
| BPS252008S-4R7M-TB8 | 4.7 | ±20％ | 180 [150] | 1.8 [2.3] | 1.8 [2.0] | |||||||||||||||||||||
| BPS252008S-6R8M-TB6 | 6.8 | ±20％ | 322 [280] | 1.6 [2.0] | 1.1 [1.3] | |||||||||||||||||||||
| BPS252008S-100M-TB6 | 10.0 | ±20％ | 575 [500] | 1.4 [1.8] | 1.0 [1.1] | |||||||||||||||||||||
•Can be customized according to individual specifications.
•Isat: Inductance decreases approximately from the actual initial value30%The DC current.
•Itemp: The temperature rises aboutΔT=40°CWhen the direct current.Depending on the circumstances of our use,ItempIs a reference value.In the final application, the circuit should be designed so that the temperature rise of the component does not exceed40℃.
