| Part Number |
L (uH) |
Tolerance |
Rdc（mΩ） Max.[Typ.] |
Isat（A） Max.[Typ.] |
Itemp（A） Max.[Typ.] |
|||||||||||||||||||||
| BPS201612S-R24M-TB8 | 0.24 | ±20％ | 11 [9.0] | 8.7 [9.2] | 8.6 [9.1] | |||||||||||||||||||||
| BPS201612S-R47M-TB8 | 0.47 | ±20％ | 19 [16] | 6.0 [6.6] | 5.1 [5.6] | |||||||||||||||||||||
| BPS201612S-1R0M-TB8 | 1.0 | ±20％ | 49 [43] | 4.0 [4.3] | 3.4 [4.0] | |||||||||||||||||||||
| BPS201612S-2R2M-TB8 | 2.2 | ±20％ | 74 [65] | 2.8 [3.3] | 2.8 [3.1] | |||||||||||||||||||||
| BPS201612S-3R3M-TB8 | 3.3 | ±20％ | 145 [121] | 2.3 [2.7] | 2.0 [2.4] | |||||||||||||||||||||
| BPS201612S-6R8M-TB8 | 6.8 | ±20％ | 275 [230] | 1.3 [1.5] | 1.2 [1.4] | |||||||||||||||||||||
•Can be customized according to individual specifications.
•Isat: Inductance decreases approximately from the actual initial value30%The DC current.
•Itemp: The temperature rises aboutΔT=40°CWhen the direct current.Depending on the circumstances of our use,ItempIs a reference value.In the final application, the circuit should be designed so that the temperature rise of the component does not exceed40℃.
