| Part Number |
L (uH) |
Tolerance |
Rdc（mΩ） Max.[Typ.] |
Isat（A） Max.[Typ.] |
Itemp（A） Max.[Typ.] |
|||||||||||||||||||||
| BPS201608S-R24M-TB6 | 0.24 | ±20％ | 22 [18] | 6.3 [6.9] | 4.4 [4.9] | |||||||||||||||||||||
| BPS201608S-R24M-TB8 | 0.24 | ±20％ | 20 [16.5] | 6.5 [7.2] | 5.2 [5.7] | |||||||||||||||||||||
| BPS201608S-R33M-TB6 | 0.33 | ±20％ | 25 [21] | 6.4 [7.0] | 4.2 [4.7] | |||||||||||||||||||||
| BPS201608S-R47M-TB6 | 0.47 | ±20％ | 31 [27] | 5.0 [5.5] | 3.4 [3.9] | |||||||||||||||||||||
| BPS201608S-R47M-TB8 | 0.47 | ±20％ | 24 [20] | 5.0 [5.5] | 4.5 [4.9] | |||||||||||||||||||||
| BPS201608S-1R0M-TB6 | 1.0 | ±20％ | 56 [48] | 3.6 [4.0] | 3.2 [3.6] | |||||||||||||||||||||
| BPS201608S-1R0M-TB8 | 1.0 | ±20％ | 52 [41] | 3.9 [4.3] | 3.6 [4.0] | |||||||||||||||||||||
| BPS201608S-2R2M-TB6 | 2.2 | ±20％ | 143 [125] | 2.3 [2.7] | 2.0 [2.3] | |||||||||||||||||||||
| BPS201608S-1R5M-TB8 | 1.5 | ±20％ | 100 [82] | 2.8 [3.3] | 1.6 [1.9] | |||||||||||||||||||||
| BPS201608S-2R2M-TB8 | 2.2 | ±20％ | 100 [84] | 2.7 [2.9] | 2.1 [2.4] | |||||||||||||||||||||
| BPS201608S-4R7M-TB8 | 4.7 | ±20％ | 286 [238] | 1.4 [1.6] | 1.4 [1.7] | |||||||||||||||||||||
•Can be customized according to individual specifications.
•Isat: Inductance decreases approximately from the actual initial value30%The DC current.
•Itemp: The temperature rises aboutΔT=40°CWhen the direct current.Depending on the circumstances of our use,ItempIs a reference value.In the final application, the circuit should be designed so that the temperature rise of the component does not exceed40℃.
